Dates Seed Remover Pitting Machine Manufacturer

Dates Seed Remover Machine Features

• High Capacity: The automatic date pitting machine can process 100kg-1000kg of dates per hour. Meets the needs of large-scale production, replacing manual labor.
• High Quality: The date seed removing machine has a pitting rate of up to 99.5%. The pitted dates retain intact flesh and have a good appearance.
• Customizable: The date pitting machine has adjustable pit spacing and interchangeable molds. It can process fruits of different sizes, ranging from Φ12mm to Φ38mm in diameter. Meets the pitting processing needs of different producers.
• Effective Design: Dates are pitted within the date seed remover machine. The pit and flesh are automatically separated and output from different outlets. This facilitates subsequent cleaning and processing.
• Flexibility: The automatic date pitting machine can be used as a standalone unit. It can also be used in a Date Washing Pitting Line. It can be integrated with washing machines, grading machines, dryers, packaging machines, etc., to create turnkey solutions.
• Safety: The date seed remover machine operates fully automatically. This avoids the risk of microbial contamination from human contact. The date pitting machine is made of food-grade stainless steel. Routine cleaning and maintenance are simple, and the product is more hygienic.

Date Pitting Process Pricinple

1. Feeding: Dates are poured into the hopper or conveyor belt. The date seed removing machine’s vibrating plate arranges the dates one by one.
2. Positioning: Each date is individually positioned in the center of a mold. The mold holds the date in place, ensuring accurate alignment of the fruit’s center.
3. Pitting: The date pitting machine automatically presses down, pushing the pit out of the date’s center. A precise mechanical structure ensures stable pressure. The pitting process does not damage or tear the fruit flesh.
4. Halving: The date seed remover machine can be customized with a halving function according to customer needs. It can cut the date directly. Alternatively, it can be partially cut to allow for the addition of ingredients (such as walnuts, sugar, etc.) to the date.
5. Discharge: The pits fall into a dedicated waste collection channel. The fruit flesh is discharged through separate channels. Different outlets ensure a clean and hygienic finished product. The entire process is continuous, automatic, and efficient.

Date Seed Removing Machine Advantages

• Automation: The date seed removing machine integrates feeding, positioning, pitting, and sorting. It operates efficiently with a high degree of automation. No manual intervention is required, reducing labor costs.
• Simple Operation: The date pitting machine is equipped with a PLC intelligent control system. The pitting speed can be freely adjusted. The user-friendly interface allows for operation by a single person. Low technical requirements for operators; easy to learn and use.
• Durable: The core components of the date seed remover machine are made of corrosion-resistant materials. Stable and reliable operation, suitable for continuous production.
• Multi-functional: The date pitting machine can process dried dates, wet dates, jujubes, apricots, plums, and other drupes. High equipment utilization and high return on investment.
• Low Loss: The date seed removing machine achieves a 99.5% pitting rate. Fruit flesh remains intact and aesthetically pleasing. Reduced manual re-inspection costs. Increased yield and commercial value.
• One-Stop Service: Gelgoog can provide customized single-machine or complete line solutions based on your production capacity targets, factory conditions, and special process requirements.

Technical Data

Model	GGZQH-190-6	GGZQH-190-7	GGZQH-190-14	GGZQH-190-26
Pitting rate	0.995	0.995	0.995	0.995
Dates Size(mm)	∅32—∅38	∅24—∅32	∅22—∅32	∅12—∅24
Capacity(pcs/h)	28800	33600	67200	124800
Power(kw)	1.5	1.5	1.5	1.5
Voltage(v)	380	380	380	380
Machine size(mm)	2300×1280×1220	2300×1280×1220	2300×1280×1220	2300×1280×1220
Machine weigh（kg）	610	610	610	610



---
